Genuine MEANWELL 240W Single Output LED Power Supply HLG-240H-36V
| MODEL | HLG-320H-12 | HLG-320H-15 | HLG-320H-20 | HLG-320H-24 |
OUTPUT | DC VOLTAGE | 12V | 15V | 20V | 24V |
| C&C REGION | 6 ~12V | 7.5 ~ 15V | 10 ~ 20V | 12 ~ 24V |
| RATED CURRENT | 22A | 19A | 15A | 13.34A |
| RATED POWER | 264W | 285W | 300W | 320.2W |
| RIPPLE & NOISE | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p |
| VOLTAGE ADJ. | 10.8~13.5V | 13.5~ 17V | 17 ~ 22V | 22 ~ 27V |
| CURRENT ADJ.RANGE | Can be adjusted by internal potential meter .or through output
cable |
| 11 ~ 22A | 9.5 ~ 19A | 7.5 ~ 15A | 6.67~13.34A |
| VOLTAGE TOLERANCE | 2.5% | 2.0% | 1.0% | 1.0% |
| LINE REGULATION | 0.5% | 0.5% | 0.5% | 0.5% |
| LOAD REGULATION | 2.0% | 1.5% | 1.0% | 0.5% |
| SETUP RISE TIME | 2500ms, 80ms at full load 230VAC /115VAC |
| HOLD UP TIME | 15ms at full load 230VAC / 115VAC |
INPUT | VOLTAGE RANGE | 90 ~ 305VAC 127 ~ 431VDC |
| FREQUENCY | 47 ~ 63Hz |
| POWER FACTOR | PF 0.95/230VAC PF 0.98/115VAC at full load and rated output voltage
PF 0.9 at 50 ~ 100% load |
| EFFICIENCY | 92% | 92% | 93% | 94% |
| AC CURRENT | 4A / 115VAC 2A / 230VAC 1.8A / 277VAC |
| INRUSH CURRENT | COLD START 75A/230VAC |
| LEAKAGE CURRENT | <0.75mA / 277VAC m |
OTHERS | MTBF | Khrs min. MIL-HDBK-217F |
| DIMENSION | 252*90*42mm (L*W*H)(HLG-320H-Blank/A/B) 256*90*42mm
(L*W*H)(HLG-320H-C) |
| PACKING | Kg |
Why Choose Us ???
Original MEANWELL brand
1. We sell 100% original real MEANWELL brand, and have the
certificate of UL, CUL, CE, CB, RoHS etc.
2.The different S/N code on surface of the products, can check the
code with MEANWELL company.
Competitive Price +A Fast Delivery + Satisfied Customer Service
1. Our goal is to provide you the right product and make you
satisfied, so please don’t hesitate to contact us via Tel or mail.
2. We shall find for you the cheapest shipping term and show you
the freight and shipping time. Regarding to the urgent order, a
quickest shipping term and freight will be advised to you for
consideration.
3. The stock info will be informed before your order, to make
everything under control.
4. We will quote to you competitive prices according to your
quantities.
5. Price could be negotiated for more and large quantity.
6. We have a technical team, if you show us your LED information,
we can find right drivers for you to match LED.
Shipping & Duties
Usually, shipping will be arranged within 2-3 Days upon payment or
deposit, from Monday to Saturday only.
Payment
To assure you the maximum comfort and satisfaction, Currently, you
can pay via T/T, L/C, WESTERN UNION, PAYPAL, More payment options
will be added in the near future.
After-sale service
All of the products we sell are with a certain time warranty.
during the warranty, anything wrong with it, like no working an
unstable output voltage or current, damaged, my corporation will be
responsible to fix it well for free and re-send it to the clients,
But, the delivery cost should be paid by purchaser himself.
We will be very glad to provide the assistance during your
installation and application at any time.
Contact Us
Your inquiry and mail will be quickly responded. Suppose you have
no ideas on choosing the right power supply, please do not hesitate
to contact us.
We will always be here and try our best to provide you our best
service !
Waiting for your kind inquiry !
